PP food container Injection Moulding Machine Thin Wall With Hopper dryer

Brand Name : VAINO

Model Number : K2-280s

Certification : CE/ISO9001:2008

Place of Origin : Ningbo,China

MOQ : 1SET

Delivery Time : 15-25 working days after confirm order and received deposit

Packaging Details : Wooden pellet Wooden case(optional)

Contact Now

PP food container Injection Moulding Machine Thin Wall With Hopper dryer



Standard configuration:

Adopt famous hydraulic components:

Yuken-Japan pump,Yuken-Japan direction valve,

Hydraulic motor for melting plastic using intermot italy-China

Back pressure valve Yuken Japan

Air switch from LG Korea

Breaker AC contactor ,single phase breaker ,three-phase breaker from Schneider france

T-slot makes the adjustment easier, compare with the screw adjustment, it has better adaptability and longer life-span





Optional function

  1. nitrogen injection devices
  2. technological meter device for plasticizing speed indication
  3. prolonged nozzle
  4. hydraulic safety interlock
  5. core pull and unscrew motor
  6. robot interface
  7. special screw
  8. Be-clear at one glance for checking the chiller water speed and temp
  9. Auto-loader
  10. Hopper dryer
  11. Chiller
  12. Mixer
  13. Crusher





SPECIFICATIONS



SPECIFICATIONS
DESCRIPTION  UNIT  K2-280s
INJECTION    A B C
SHOT VOLUME  CM3 700 792 930
SHOT WEIGHT G 636 720 845
(PS) OZ 22.2  25.2  29.5
SCREW DIAMETER MM 55 60 65
INJECTION PRESSURE  MPA 211 177 151
SCREW L:D RATIO    22:1 20:1 18.5:1
SCREW STROKE  MM 300
SCREW SPEED (STEPLESS) R/MIN  0~150
CLAMPING UNIT
CLAMPING FORCE  KN 2800
OPENING STROKE  MM 570
PLATEN SIZE  MM*MM 870*850
SPACE BETWEEN TIE BARS  MM*MM 610*590
MOLD THICKNESS (MIN-MAX) MM 220~620
MAX.DAYLIGHT  MM 1190
HYDRAULIC EJECTION STROKE  MM 160
HYDRAULIC EJECTION FORCE  KN 77
POWER UNIT
HYDRAULIC SYSTEM PRESSURE  MPA 17.5
PUMP MOTOR(V/S) KW 22/28.3
HEATING CAPACITY KW  18
NUMBER OF TEMP CONTROL ZONES   5+(NOZZLE )
GENERAL
DRY-CYCLE TIME  SEC 5
OIL TANK CAPACITY  L 380
MACHINE DIMENSIONS MXMXM 6.4*1.5*2.2
MACHINE WEIGHT KG 11000
