0.4mm thin wall thickness PP automatic blow moulding machine / blow mold machine

VAINO INTERNATIONAL LIMITED
Contact Now

0.4mm thin wall thickness PP automatic blow moulding machine / blow mold machine

Brand Name : VAINO

Model Number : K2-220s

Certification : CE/ISO9001:2008

Place of Origin : Ningbo,China

MOQ : 1SET

Delivery Time : 15-25 working days after confirm order and received deposit

Packaging Details : Wooden pellet Wooden case(optional)

SHOT VOLUME : 381,470,569

SHOT WEIGHT : 347,429,520G

HYDRAULIC EJECTION STROKE : 150mm

HYDRAULIC EJECTION FORCE : 67kn

MACHINE WEIGHT : 6800KG

MACHINE DIMENSIONS : 5.4X1.3X2.1

Contact Now

0.4mm thin wall thickness PP automatic blow moulding machine / blow mold machine



Detailed Product Description



HIGH-SPEED INJECTION MOLDING MACHINE

It also helps protect the system from fluid hammer.

This protects system components particularly pipe work, from both potentially destructive forces. An additional benefit is the additional energy that can be store while the pump is subject to low demand. These are often placed close to the demand to help over come restrictions and drag from long pipe work runs. An accumulator can maintain the pressure in a system for periods when these are slight leaks without the pump being cycled on an off constantly. when the temperature changes cause pressure excursions the accumulator helps absorb them.

These series machines take the accumulator to help inject, which having high cost performance improve the speed ,quicken the machine circle time, higher the efficiency, and especially suitable for the ultrathin, precious and complicated products.



SPECIFICATIONS



SPECIFICATIONS
DESCRIPTION  UNIT  K2-220s
INJECTION    A B C
SHOT VOLUME  CM3 381 470 569
SHOT WEIGHT G 347 429 520
(PS) OZ 12.1  15.0  18.1
SCREW DIAMETER MM 45 50 55
INJECTION PRESSURE  MPA 217 176 145
SCREW L:D RATIO    22:1 20:1 18:1
SCREW STROKE  MM 240
SCREW SPEED (STEPLESS) R/MIN  0~200
CLAMPING UNIT
CLAMPING FORCE  KN 2200
OPENING STROKE  MM 480
PLATEN SIZE  MM*MM 745*745
SPACE BETWEEN TIE BARS  MM*MM 510*510
MOLD THICKNESS (MIN-MAX) MM 200~560
MAX.DAYLIGHT  MM 1040
HYDRAULIC EJECTION STROKE  MM 150
HYDRAULIC EJECTION FORCE  KN 67
POWER UNIT
HYDRAULIC SYSTEM PRESSURE  MPA 17.5
PUMP MOTOR(V/S) KW 18.5/28.3
HEATING CAPACITY KW  13.1
NUMBER OF TEMP CONTROL ZONES   4+(NOZZLE )
GENERAL
DRY-CYCLE TIME  SEC 4.5
OIL TANK CAPACITY  L 310
MACHINE DIMENSIONS MXMXM 5.4*1.3*2.1
MACHINE WEIGHT KG 6800







0.4mm thin wall thickness PP automatic blow moulding machine / blow mold machine

0.4mm thin wall thickness PP automatic blow moulding machine / blow mold machine
