high production capacity low electricity consumption servo injection machine K1-400
CLAMPING PART
Moving platen flowing bearing system ,have raised the efficiency of open /close moldand reduces the energy consumption
5 points vertical double toggle clamping system
T slot mold suitable for different mold setting
Automatic meticulous mold adjustment according to the clamping force
Cavity oil cylinder required for high speed movements ,can alleviate the baffling
INJECTION PART
High quality linear guider couple ensure and accurate injection
It adopts the double oil circuit injection machinery to satisfy the injection speed requirements of high precision products .
Optimized screw design to realize high-speed injection and meet the requirements of thin -wall products molding
Specific screw and barrel designs are available for processing different material requirements
CONTROL PART
Adopt imported computer which special for injection machine ,its processed and controlled by CPU,This is to expedite response from control system as well as to improve operational accuracy of the machine
Industrial quality components and circuit hardware design provide a stable and reliable control system
Ultra bright LED’S are provide for input and out put point inspection providing convenient indication of the machine ‘s operation and machine serving
SPECIFICATIONS
| SPECIFICATIONS | | | | |
| DESCRIPTION | UNIT | K1-400 |
| INJECTION | | A | B | C |
| SHOT VOLUME | CM3 | 1385 | 1810 | 2290 |
| SHOT WEIGHT | G | 1260 | 1646 | 2084 |
| (PS) | OZ | 44.1 | 57.5 | 72.8 |
| SCREW DIAMETER | MM | 70 | 80 | 90 |
| INJECTION PRESSURE | MPA | 206 | 158 | 125 |
| SCREW L:D RATIO | | 21:1 | 21:1 | 19:1 |
| SCREW STROKE | MM | 360 |
| SCREW SPEED (STEPLESS) | R/MIN | 0~135 |
| CLAMPING UNIT | | | | |
| CLAMPING FORCE | KN | 4000 |
| OPENING STROKE | MM | 670 |
| PLATEN SIZE | MM*MM | 1060*1040 |
| SPACE BETWEEN TIE BARS | MM*MM | 730*710 |
| MOLD THICKNESS (MIN-MAX) | MM | 250~730 |
| MAX.DAYLIGHT | MM | 1400 |
| HYDRAULIC EJECTION STROKE | MM | 185 |
| HYDRAULIC EJECTION FORCE | KN | 111 |
| POWER UNIT | | | | |
| HYDRAULIC SYSTEM PRESSURE | MPA | 17.5 |
| PUMP MOTOR(V/S) | KW | 37/43 |
| HEATING CAPACITY | KW | 32.3 |
| NUMBER OF TEMP CONTROL ZONES | | 5+(NOZZLE ) |
| GENERAL | | | | |
| DRY-CYCLE TIME | SEC | 5.1 |
| OIL TANK CAPACITY | L | 820 |
| MACHINE DIMENSIONS | MXMXM | 8.6*1.8*2.3 |
| MACHINE WEIGHT | KG | 17000 |
HYDRRULICS
Servo System
Oil suck filiter
Oil temperature control and alarm
By-pass oil filter
ELECTRONICS
8.7' lcd solor screen
200sets of mold memory
Barrel temperature monitoring and thermocouple break alarm
System hardware i/o testing function
Interface for printer and floppy drlver
Electric motor safety protection
Emergency stop safeguard device
OPTIONRL DEVICE
Wide range of injection unit for specific appliaction
Spacific material screw and barrel
Accumulator fast injection
Core pull fittings
Air blast fittings
Glass water regulations
Extended nozzle
